Retrorectal Mass: An Atypical Case Presentation of Metastatic Myxoid Liposarcoma

Abstract

Background

Retrorectal masses often pose a diagnostic and management challenge due to their rarity and heterogeneous etiologies. Myxoid liposarcoma (MLS) is a lipomatous malignancy that can have atypical, extra-pulmonary metastatic sites.

Summary

A 36-year-old male patient who initially underwent a radical resection of a left posterior thigh MLS was found to have an asymptomatic 9 cm solitary retrorectal mass during a surveillance MRI a year later. Given the clinical history and imaging characteristics, the mass was suspected to be a solitary metastatic disease from his MLS. He underwent chemotherapy followed by radiation therapy, after which his tumor demonstrated response without evidence of further metastatic disease. The patient then underwent a low anterior resection, and the final pathology confirmed metastatic MLS.

Conclusion

Metastatic MLS to the retrorectal space has not previously been reported and should be part of the differential diagnosis when evaluating a retrorectal mass, especially in the context of prior known primary disease. This case report also highlights the efficacy of a radical resection with a total mesorectal excision in the surgical management of retrorectal metastatic MLS.

Key Words

metastatic myxoid liposarcoma; mesorectal; presacral; retrorectal; pelvic mass

Case Description

Retrorectal masses are uncommon lesions found in the potential space confined by the sacrum posteriorly, rectum anteriorly, and peritoneal reflection superiorly. They often pose a diagnostic and management challenge due to their rarity and heterogeneous etiologies.¹ Based on the classification proposed by Uhlig and Johnson,² etiologies of retrorectal masses are categorized into congenital, neurogenic, osseous, inflammatory, and miscellaneous, with benign and malignant lesions in each category. We describe a unique case of a patient with a history of surgically treated primary myxoid liposarcoma (MLS) of the left posterior thigh who presented with a solitary retrorectal mass.

The patient is a 36-year-old healthy male who presented to another hospital three years ago with a left posterior thigh mass. After evaluation of local extent with MRI, the biopsy revealed high-grade lipomatous malignancy with the presence of round cells. DNA damage-inducible transcript 3 (DDIT3) gene translocation was detected on fluorescence in situ hybridization, confirming the diagnosis of MLS. CT chest showed no pulmonary metastasis. The patient underwent neoadjuvant radiation therapy followed by radical resection. The final pathology revealed a 10 cm tumor with negative margins.

Although initial surveillance imaging was negative, pelvic MRI at one-year follow-up revealed interval development of a 9 cm well-circumscribed, heterogeneous retrorectal mass without regional lymphadenopathy (Figure 1). Staging CT of the chest, abdomen, pelvis did not show any other sites of disease. At this time, the patient was referred to us. Metastatic MLS was highly suspected given his history and subtle fat components in the tumor seen on a careful review of the imaging. The patient was treated with three cycles of trabectedin 1.5 mg/m² intravenously every three weeks. Upon completion, restaging showed overall stable disease for the retrorectal tumor and, again, no other metastase.

Figure 1. Cross-sectional Images of Retrorectal Mass. Published with Permission

A) Sagittal reformat CT image shows retrorectal mass (thick arrow) with broad area of contact with rectum (thin arrow); B) coronal T1 MRI image shows isointense mesorectal mass. Focal areas of T1 hyperintense signal in mass are consistent with fat (arrowhead); C) sagittal T2 MRI image shows heterogeneously hyperintense mass (thick arrow) relative to muscle. Mass abuts rectum (thin arrow) without gross invasion; D) sagittal post-contrast T1 with fat saturation MRI image shows heterogeneous enhancement of mass

The patient then underwent radiation therapy with 5000cGy delivered over 25 fractions. Repeat CT now showed partial response to therapy, with decreased tumor size (>20%) and heterogeneous internal characteristics with less enhancing components. He remained asymptomatic and notably, without evidence of metastatic disease elsewhere. After consultations with both a surgical oncologist and a colorectal surgeon, the patient consented to surgical resection.

At surgery, the tumor was found to be confined within the posterior mesorectal envelope. Given the extent of involvement, we proceeded with low anterior resection and diverting loop ileostomy to achieve complete en bloc resection (Figure 2). In the immediate postoperative period, the patient had high ileostomy output that was managed conservatively but otherwise had an uneventful recovery. He was discharged on postoperative day 5.

The final pathology revealed a 6.2 cm metastatic MLS with negative margins. The tumor abutted the rectum without invasion into the muscularis propria.

Figure 2. Low Anterior Resection Surgical Specimen. Published with Permission

A CT of the chest, abdomen, pelvis performed six weeks postoperatively was negative for residual or metastatic disease and served as a new baseline imaging study. The patient then underwent an uneventful ileostomy reversal three months later. At his most recent follow-up six months postoperatively, he remains disease-free.

Discussion

The differential diagnosis of a retrorectal mass is wide given a variety of tissue types in close proximity.¹ A review by Baek et al³ including 1,708 patients reported an extensive list of differential diagnoses for primary retrorectal masses. Most lesions were benign (70%) and the most common category overall was congenital (60.4%). Primary liposarcoma had a reported prevalence of 0.8% of retrorectal masses.

Liposarcomas are malignant mesenchymal tumors of adipocytic differentiation with three main subtypes: well-differentiated/dedifferentiated, myxoid/round cell, and pleomorphic.⁴ MLS is the second most common subtype, representing 20 to 30% of all liposarcomas. Its incidence peaks in the fourth and fifth decades of life,^5,6 but MLS is also the predominant subtype of liposarcoma affecting the pediatric population.⁷ It is characterized by pathognomonic chromosomal translocation resulting in an oncogenic FUS-DDIT3 fusion protein.⁶ Presence of round cells is characteristic of high-grade disease.⁵

The most common sites for primary presentation of MLS are the extremities and trunk. After complete resection, local recurrence or distant metastatic disease can be seen in up to 40% of cases, typically in high-grade (=round cell) tumors.^5,8,9 Other factors associated with increased risk of local or distant recurrence include older age, male gender, large tumor size, and depth of the primary tumor.⁵ Timing of recurrence of MLS is highly variable amongst published reports. Most cases of recurrence disease occur within the 2 to 3 years after primary resection, although the time interval ranges from 0 (synchronous) to almost 12 years (very late).^8,10‒12

Unlike other soft tissue sarcomas, potential metastatic sites for MLS are uniquely extra-pulmonary to fat-bearing areas of the body, including the retroperitoneum and spine.^5,9,10,13 This pattern of metastasis as opposed to second primary sites is supported by detailed molecular tumor characterization.^14,15 Other reported atypical metastatic sites include the heart and small bowel mesentery. To our knowledge, metastatic disease to the retrorectal space, as in this case, has not been previously reported.

It is important to mention that our patient did not undergo a preoperative biopsy of his retrorectal mass. Based on history and imaging characteristics, we determined that the retrorectal mass was likely metastatic MLS from his primary tumor site (thigh) and proceeded with the treatment accordingly with neoadjuvant therapy and resection. To our knowledge, literature is scarce on the risk of needle tract seeding after a percutaneous biopsy. Two recent papers discuss this in the setting of sarcoma (all body sites), including MLS, that found seeding to be a very rare complication (0.37% to 2%).^16,17 The caveat is that these studies looked at primary and not metastatic disease, as was the case for our patient.

The treatment of locally advanced and metastatic MLS involves a multidisciplinary approach. MLS is uniquely sensitive to radiation and systemic therapy. MLS is particularly sensitive to trabectedin, but radiographic responses have been seen with traditional chemotherapy agents, including anthracyclines and ifosfamide.^18‒20 A phase II study of trabectedin in patients with locally advanced MLS resulted in pathologic complete response in three and partial pathologic responses in 12 out of 23 patients.²¹ Another large trial, in which neoadjuvant trabectedin was compared to neoadjuvant anthracycline/ifosfamide for patients with primary MLS, showed that trabectedin might be at least as effective but with significantly less toxicity.²²

The indication for surgical management of metastatic disease is less well defined. In this case, after a multidisciplinary discussion, we felt that surgical resection was indicated given tumor response to systemic therapy and confirmed solitary metastasis. Various surgical approaches, including anterior (transabdominal), posterior (perineal, trans-sacral, and paracoccygeal), and combined, have been described. The choice of approach depends on the sacral level of the tumor, size, involvement of sacral nerves, or other major structures.³ Given the cephalad position of the tumor above the level of S4, we were able to achieve en bloc resection with negative margins via an anterior approach with a low anterior resection. Overall, published data regarding outcomes following resection of metastatic MLS are limited. Some recent evidence suggests that MLS may be one subtype of soft tissue sarcoma in which select patients with metastatic disease may benefit from surgery.^11,12,23

Conclusion

A wide differential diagnosis for a retrorectal mass is essential to identify the etiology and guide treatment correctly. This case report describes a previously unreported presentation of a metastatic MLS as a solitary retrorectal mass. After a multidisciplinary discussion and multimodality therapy, complete resection was achieved via a low anterior resection adhering to the principles of total mesorectal excision.

Lessons Learned

Metastatic MLS may present in the retrorectal space and should be considered as part of the differential diagnosis, especially in the clinical context of an existing or prior primary disease elsewhere. A retrorectal MLS without invasion to the presacral fascia may be safely excised by total mesorectal excision.

References

1. Hobson KG, Ghaemmaghami V, Roe JP, Goodnight JE, Khatri VP. Tumors of the retrorectal space. Dis Colon Rectum. 2005;48(10):1964-1974. doi:10.1007/s10350-005-0122-9
2. Uhlig BE, Johnson RL. Presacral tumors and cysts in adults. Dis Colon Rectum. 1975;18(7):581-589. doi:10.1007/BF02587141
3. Baek SK, Hwang GS, Vinci A, et al. Retrorectal tumors: a comprehensive literature review. World J Surg. 2016;40(8):2001-2015. doi:10.1007/s00268-016-3501-6
4. Rizer M, Singer AD, Edgar M, Jose J, Subhawong TK. The histological variants of liposarcoma: predictive MRI findings with prognostic implications, management, follow-up, and differential diagnosis. Skeletal Radiol. 2016;45(9):1193-1204. doi:10.1007/s00256-016-2409-4
5. Haniball J, Sumathi VP, Kindblom LG, et al. Prognostic factors and metastatic patterns in primary myxoid/round-cell liposarcoma. Sarcoma. 2011;2011:538085. doi:10.1155/2011/538085
6. Lee ATJ, Thway K, Huang PH, Jones RL. Clinical and molecular spectrum of liposarcoma. J Clin Oncol. 2018;36(2):151-159. doi:10.1200/JCO.2017.74.9598
7. Alaggio R, Coffin CM, Weiss SW, et al. Liposarcomas in young patients: a study of 82 cases occurring in patients younger than 22 years of age. Am J Surg Pathol. 2009;33(5):645-658. doi:10.1097/PAS.0b013e3181963c9c
8. Spillane AJ, Fisher C, Thomas JM. Myxoid liposarcoma--the frequency and the natural history of nonpulmonary soft tissue metastases. Ann Surg Oncol. 1999;6(4):389-394. doi:10.1007/s10434-999-0389-5
9. Dürr HR, Rauh J, Baur-Melnyk A, et al. Myxoid liposarcoma: local relapse and metastatic pattern in 43 patients. BMC Cancer. 2018;18(1):304. Published 2018 Mar 20. doi:10.1186/s12885-018-4226-8
10. Fuglø HM, Maretty-Nielsen K, Hovgaard D, Keller JØ, Safwat AA, Petersen MM. Metastatic pattern, local relapse, and survival of patients with myxoid liposarcoma: a retrospective study of 45 patients. Sarcoma. 2013;2013:548628. doi:10.1155/2013/548628
11. Langmans C, Cornillie J, van Cann T, et al. Retrospective analysis of patients with advanced liposarcoma in a tertiary referral center. Oncol Res Treat. 2019;42(7-8):396-404. doi:10.1159/000500608
12. Shinoda Y, Kobayashi E, Kobayashi H, et al. Prognostic factors of metastatic myxoid liposarcoma. BMC Cancer. 2020;20(1):883. Published 2020 Sep 14. doi:10.1186/s12885-020-07384-1
13. Lin S, Gan Z, Han K, Yao Y, Min D. Metastasis of myxoid liposarcoma to fat-bearing areas: A case report of unusual metastatic sites and a hypothesis. Oncol Lett. 2015;10(4):2543-2546. doi:10.3892/ol.2015.3585
14. de Vreeze R, de Jong D, Nederlof P, et al. Multifocal myxoid liposarcoma--metastasis or second primary tumor?: a molecular biological analysis. J Mol Diagn. 2010;12(2):238-243. doi:10.2353/jmoldx.2010.090117
15. Antonescu CR, Elahi A, Healey JH, et al. Monoclonality of multifocal myxoid liposarcoma: confirmation by analysis of TLS-CHOP or EWS-CHOP rearrangements. Clin Cancer Res. 2000;6(7):2788-2793.
16. Van Houdt WJ, Schrijver AM, Cohen-Hallaleh RB, et al. Needle tract seeding following core biopsies in retroperitoneal sarcoma. Eur J Surg Oncol. 2017;43(9):1740-1745. doi:10.1016/j.ejso.2017.06.009
17. Berger-Richardson D, Swallow CJ. Needle tract seeding after percutaneous biopsy of sarcoma: Risk/benefit considerations. Cancer. 2017;123(4):560-567. doi:10.1002/cncr.30370
18. Jones RL, Fisher C, Al-Muderis O, Judson IR. Differential sensitivity of liposarcoma subtypes to chemotherapy. Eur J Cancer. 2005;41(18):2853-2860. doi:10.1016/j.ejca.2005.07.023
19. Patel S, von Mehren M, Reed DR, et al. Overall survival and histology-specific subgroup analyses from a phase 3, randomized controlled study of trabectedin or dacarbazine in patients with advanced liposarcoma or leiomyosarcoma. Cancer. 2019;125(15):2610-2620. doi:10.1002/cncr.32117
20. Demetri GD, von Mehren M, Jones RL, et al. Efficacy and safety of trabectedin or dacarbazine for metastatic liposarcoma or leiomyosarcoma after failure of conventional chemotherapy: results of a phase III randomized multicenter clinical trial. J Clin Oncol. 2016;34(8):786-793. doi:10.1200/JCO.2015.62.4734
21. Gronchi A, Bui BN, Bonvalot S, et al. Phase II clinical trial of neoadjuvant trabectedin in patients with advanced localized myxoid liposarcoma. Ann Oncol. 2012;23(3):771-776. doi:10.1093/annonc/mdr265
22. Gronchi A, Ferrari S, Quagliuolo V, et al. Histotype-tailored neoadjuvant chemotherapy versus standard chemotherapy in patients with high-risk soft-tissue sarcomas (ISG-STS 1001): an international, open-label, randomised, controlled, phase 3, multicentre trial [published correction appears in Lancet Oncol. 2017 Jun;18(6):e301]. Lancet Oncol. 2017;18(6):812-822. doi:10.1016/S1470-2045(17)30334-0
23. Estourgie SH, Nielsen GP, Ott MJ. Metastatic patterns of extremity myxoid liposarcoma and their outcome. J Surg Oncol. 2002;80(2):89-93. doi:10.1002/jso.10093

Authors

Cyprich J^a; Yoon D^b; Shin J^b; Patel DB^c; Thomas J^d; Tseng WW^e

Author Affiliations

1. Keck School of Medicine, University of Southern California, Los Angeles, CA 90033
2. Division of Colorectal Surgery, Department of Surgery, Keck School of Medicine, University of Southern California, Los Angeles, CA 90033
3. Department of Radiology, Keck School of Medicine, University of Southern California, Los Angeles, CA 90033
4. Department of Medicine, Norris Comprehensive Cancer Center, University of Southern California, Los Angeles, CA 90033
5. Division of Breast, Endocrine and Soft Tissue Surgery, Department of Surgery, Keck School of Medicine, University of Southern California, Los Angeles, CA 90033

Corresponding Author

William W. Tseng, MD
Associate Professor of Surgery
USC Sarcoma Surgical Oncology
1510 San Pablo Street, HCC-I Ste. 514
Los Angeles, CA 90033
Phone: (323) 865-1535
Email: william.tseng@med.usc.edu

Disclosure Statement

The authors have no conflicts of interest to disclose.

Funding/Support

The authors have no relevant financial relationships or in-kind support to disclose.

Received: August 26, 2021
Revision received: September 13, 2021
Accepted: November 1, 2021
